IE-PIC-M12X-S-22/26
IE-PIC-M12X-S-22/26

IE-PIC-M12X-S-22/26

Contact, without, Socket connector

Item No. 2673440000
Download data sheet Product Downloads
Accessories 1 Is accessory of 3 Related products 2
Approvals General ordering data Abmessungen und Gewichte Environmental Product Compliance Technical data customisable plug-in connectors General Info Electrical properties Classifications

Approvals

ROHS
Conform

General ordering data

Version
Contact, without, Socket connector
Order No.
2673440000
Type
IE-PIC-M12X-S-22/26
GTIN (EAN)
4050118765359
Qty.
100 items

Abmessungen und Gewichte

Peso neto
0.063 g

Environmental Product Compliance

RoHS Compliance Status
Compliant with exemption
RoHS Exemption (if applicable/known)
6c
REACH SVHC
Lead 7439-92-1
SCIP
67cf1078-beca-4687-860b-dc475a6ec24a

Technical data customisable plug-in connectors

Coding
X-coded
Conductor cross-section, max.
0.14 mm²
Conductor cross-section, min.
0.34 mm²
Connection cross-section
AWG 22 - AWG 26
Contact material
Copper alloy
Gold-plated
LED
No
Nominal current
1 A
Number of poles
1
Protection degree
IP00
Shield connection
No
Threaded ring material
None
Type of connection
Crimp connection

General Info

Number of poles
1
Connection 1
M12 Contact
Connection 2
Crimp
Filetage du raccordement
sans
Materiale dei contatti
Lega di rame
dorata
Grado di protezione
IP00

Electrical properties

Contact resistance
≤ 10 mΩ

Classifications

ETIM 8.0
EC002635
ETIM 9.0
EC002635
ETIM 10.0
EC002635
ECLASS 14.0
27-44-01-16
ECLASS 15.0
27-44-01-16
