WAD 12 MC NE GE
WAD 12 MC NE GE

WAD 12 MC NE GE

Repère de groupes, Protection, 36.2 x 11.9 mm, WDU 16, WDU 35, jaune

Ürün No. 2445080000
Veri sayfasını indir Mühendislik desteği Ürün İndirmleri
aksesuarıdır 21 İlgili ürünler 2
Approvals Informations générales de commande 치수 및 중량 Temperatures Conformité environnementale du produit General data Изображения продукции Classifications

Approvals

ROHS
Conform

Informations générales de commande

Version
Repère de groupes, Protection, 36.2 x 11.9 mm, WDU 16, WDU 35, jaune
Order No.
2445080000
Type
WAD 12 MC NE GE
GTIN (EAN)
4050118458213
Förp.
32 items

치수 및 중량

Height
36,2 mm
높이 (인치)
1,425 inch
Width
11,9 mm
Width (inches)
0,469 inch
Net weight
1,349 g

Temperatures

Operating temperature range
-40...100 °C

Conformité environnementale du produit

RoHS Compliance Status
Conforme sans exemption
REACH SVHC
No SVHC above 0.1 wt%
Ślad węglowy produktu
  • Kołyska do bramy:
    0.462 kg CO2 eq.

General data

Application/manufacturer
WDU 16
WDU 35
Basic material
Polyamide 66
Colour
yellow
compatible printer
[PRINTJET CONNECT](~/p/2715590000)
Halogen
No
Number of markers per combination
1 MultiCard = Cover
Number of markers per packaging unit
  • Form of supply:
    MultiCard
Operating temperature range
-40...100 °C
Operating temperature range, max.
100 °C
Operating temperature range, min.
-40 °C
Orientation of print
horizontal und vertikal
Printed characters
sin imprimir
UL 94 flammability rating
V-2
Width
11,9 mm

Изображения продукции

Подпись к рисунку - 05
Ritning

Classifications

ETIM 8.0
EC000761
ETIM 9.0
EC000761
ETIM 10.0
EC000761
ECLASS 14.0
27-28-11-01
ECLASS 15.0
27-28-11-01
