CRMKIT S 115VAC 2CO L UL

CRMKIT S 115VAC 2CO L UL

, Number of contacts: 2, CO contact AgNi, Rated control voltage: 115 V AC, Continuous current: 12 A, PUSH IN, Screw connection, Test button available: No

Produkt ID 8000158984
Download datablad Product Downloads
Anvendte produkter 112
General ordering data Rozměry a hmotnosti Temperatures Control side Lado de carga Obecné údaje Insulation coordination Connection data Classifications

General ordering data

Version
, Number of contacts: 2, CO contact AgNi, Rated control voltage: 115 V AC, Continuous current: 12 A, PUSH IN, Screw connection, Test button available: No
Order No.
8000158984
Type
CRMKIT S 115VAC 2CO L UL

Rozměry a hmotnosti

Depth
72,5 mm
Depth (inches)
2,854 inch
Height
97 mm
Altura (pulgadas)
3,819 inch
Width
31 mm
Szélesség (coll)
1,22 inch

Temperatures

Ambient temperature
-20 °C…70 °C

Control side

Rated control voltage
115 V AC
Rated current AC
72.6 mA
Power rating
1.8 VA
Coil resistance
158 Ω ± 10 %
Status indicator
Green LED
Coil voltage of the replacement relay deviating from the rated control voltage
No
Coil voltage of the replacement relay
24 V AC

Lado de carga

Rated switching voltage
250 V AC
Continuous current
12 A
Napięcie łączeniowe AC, max.
250 V
Brytspänning DC, max.
250 V
AC switching capacity (resistive), max.
3000
DC switching capacity (resistive), max.
288 W @ 24 V
Switch-on delay
≤ 20 ms
Switch-off delay
≤ 12 ms
Contact type
2 CO contact (AgNi)
Mechanical service life
2 x 107 switching cycles

Obecné údaje

Operating altitude
≤ 2000 m
nad hladinou moře
Mounting rail
TS 35
Test button available
No
Colour
black
UL94 flammability rating component
  • Component:
    Socket
  • UL94 flammability rating:
    V-0
  • Component:
    Relay cover
  • UL94 flammability rating:
    V-2

Insulation coordination

Pollution severity
2
서지 전압 범주
II
Dielectric strength for control side - load side
4 kVeff / 1 Min.
Dielectric strength of neighbouring contacts
3 KVeff / 1 Min.
Dielectric strength to mounting rail
3 kVeff / 1 min.
Protection degree
IP20

Connection data

Wire connection method
PUSH IN
Screw connection
Stripping length, rated connection
8 mm
Clamping range, rated connection
1,5 mm²
Clamping range, min.
0,5 mm²
Clamping range, max.
1,5 mm²
Wire cross-section, solid, min.
0,5 mm²
Wire cross-section, solid, max.
1,5 mm²
Wire cross-section, solid, min. (AWG)
AWG 20
Wire cross-section, solid, max. (AWG)
AWG 16
Conductor cross-section, flexible, AEH (DIN 46228-1), max.
1,5 mm²
Twin wire-end ferrules, max.
1,5 mm²
Blade size
0.6 x 3.5 mm

Classifications

ETIM 8.0
EC001437
ETIM 9.0
EC001437
ETIM 10.0
EC001437
ECLASS 14.0
27-37-16-01
ECLASS 15.0
27-37-16-01
