特性
| 版本 | 重载接插件, 附件, 编码元件 |
| 订货号 | 1471500000 |
| 类型 | DSTV COBU5 |
| GTIN (EAN) | 4008190178543 |
| 数量 | 100 PC |
| 直径 | 5 mm |
| 净重 | 2.58 g |
| RoHS 合规状态 | 合规，无例外 |
| REACH SVHC | No SVHC above 0.1 wt% |
| 工程数据 | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_79489) |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.1471500000) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1471500000) |
| 产品目录 | [Catalogues in PDF-format](LINK/Catalog.html) |
| 样本 |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC002311 |
| ETIM 7.0 | EC002311 |
| ETIM 8.0 | EC002311 |
| ETIM 9.0 | EC002311 |
| ECLASS 9.0 | 27-44-02-03 |
| ECLASS 9.1 | 27-44-02-03 |
| ECLASS 10.0 | 27-44-02-03 |
| ECLASS 11.0 | 27-44-02-03 |
| ECLASS 12.0 | 27-44-02-03 |
| ECLASS 13.0 | 27-44-02-03 |
| ECLASS 14.0 | 27-44-02-03 |
| ROHS | 一致 |
