Properties
| Version | Built-in plugs, M12, PG 9, Number of poles: 2, 2 m |
| Order No. | 1279480200 |
| Type | SAIE-M12B-PB-2.0U HW |
| GTIN (EAN) | 4050118071092 |
| Qty. | 1 items |
| Net weight | 142 g |
| RoHS Compliance Status | Compliant |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | ebf89fc8-a87f-4691-b87a-dfb9921774b4 |
| Cable length | 2 m |
| Core cross-section | 0.25 mm² |
| Number of poles | 2 |
| PE function | No |
| Sheathing colour | violet (similar to RAL 4001) |
| Cable glands | PG 9 |
| Coding | B-coded |
| Conductor cross-section, max. | 0.25 mm² |
| Contact surface | Gold-plated |
| Housing main material |
Zinc diecast
nickel-plated |
| Number of poles | 2 |
| Plugging cycles | ≥ 500 |
| Pollution severity | 3 |
| Protection degree | IP68 |
| Rated current | 4 A |
| Rated voltage | 250 V |
| Temperature range of housing | -20 … +60 °C |
| Type of connection | Socket connector |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC002635 |
| ETIM 7.0 | EC003570 |
| ETIM 8.0 | EC003570 |
| ETIM 9.0 | EC003570 |
| ECLASS 9.0 | 27-44-01-03 |
| ECLASS 9.1 | 27-44-01-03 |
| ECLASS 10.0 | 27-44-01-03 |
| ECLASS 11.0 | 27-44-01-03 |
| ECLASS 12.0 | 27-44-01-03 |
| ECLASS 13.0 | 27-44-01-03 |
| ECLASS 14.0 | 27-44-01-03 |
| ROHS | Conform |
